TORO SUPER ISOTRONIC

MASCHIO GASPARDO UK LTD Stand: 1126, DEMO8, DD05

MASCHIO GASPARDO offers solutions of great interest thanks to the consolidated experience matured in more than 50 years of history through a wide range of equipment distinguished by robustness, versatility and ease of use. The power harrows range by MASCHIO GASPARDO for soil preparation is one of the most complete and reliable on the market, offering high performance and high quality products to farmers all over the world. With the present offer, MASCHIO GASPARDO is able to satisfy the different needs of all types of customers, from small farmers to big companies.







MASCHIO GASPARDO's latest innovation is TORO SUPER ISOTRONIC, the new high quality folding power harrow with ISOBUS communication protocol, already winner of the Technical Innovation Award at EIMA INTERNATIONAL 2021. Evolution of TORO model, it features many mechanical, structural and electronic innovations, making it a unique equipment on the market. A new efficient solution that ensures the machine to maximise performance and robustness.

TORO SUPER ISOTRONIC is the first power harrow with ISOBUS communication system. All working parameters can be displayed through the tractor's ISOBUS terminal: this simplifies the use of the equipment for the operator and optimises the life cycle of the power harrow.

Knowing all working parameters in real time and being able to change them also saves time, improves field performance and reduces costs. It is possible to export the work data for diagnosis or processing in order to increase the efficiency of use of TORO ISOTRONIC.

A series of sensors distributed throughout the machine allow the main functions to be constantly monitored for full control of the equipment's operation. In particular, the operator can check the power absorbed, the temperature of the oil in the gearboxes, the rotating speed of the rotors, the slip of the cardan shafts, the actual working depth, the misalignment of the rollers, the correct positioning of cardan joints when closing (“Salvacardani” is a patanted innovation), the hours and hectares worked. An innovative solution using two new patents allows a load cell to monitor the power absorbed to increase efficiency during work.

The stress level of the central gearbox is monitored in real time, allowing immediate operator reaction if necessary.

Calculating performance indicators and scheduling maintenance has never been easier. Data are also easily exported via USB stick or the web.

The farmer, thanks to the functions of the latest generation equipment, with web-based management of the working parameters (telemetry) can also take advantage of the tax benefits of the tax credit provided.

In addition, the numerous patented technical-structural solutions (5 new patents) guarantee maximum robustness and an optimal and sustainable ground refinement, also managing power absorption in the best possible way.

TORO SUPER ISOTRONIC ensures extraordinary sturdiness thanks to its reinforced frame, innovative structural improvements and new bearings for the roller range known as "Blindato": they protect the equipment from any type of contamination and allow greater consistency in the quality of work in the field whatever the ground conditions.

A new oil recirculation system has also been designed, using a reservoir inside the third point hitch frame, driven by a gear pump. The benefits are many: reduced operating temperatures of the central gearbox, less degradation of the oil properties, increased oil change intervals, reduced risk of downtime and increased productivity.

All these technical innovations are designed to ensure first-class mechanical reliability and total protection against external contamination.

These innovations are in addition to well-proven solutions, such as the air-cooling device for the central gearboxes and the quick release system for the 16 mm thick tines. The transmission body, reinforced with high-strength steel, is made up of a double box structure: with an internal sheet thickness of 6 mm and an external one of 5 mm, greater rigidity and strength are guaranteed. This allows high performance in a wide range of operating conditions.

The machine can be combined with tractors of up to 400 HP and is available in three working widths: 5, 6 and 7 metres. The maximum tillage depth is hydraulically adjustable up to 28 cm by using the roller drive. Road transport is reliable thanks to hydraulic safety couplings with a transport width of only 2.4 metres.

For a more balanced combination, TORO SUPER ISOTRONIC can be combined with BARRA CENTAURO and front hopper PA 2 thanks to the COMBI coupling. In a single step it is possible to refine the soil, sowing  and fertilize. This version allows to exploit the soil working action carried out by the folding power harrow together with the strong structure of the seeding bar with seeding units arranged in two rows. This combination provides excellent weight distribution in the tractor to the distinct advantage of traction, thus reducing soil compaction and improving manoeuvrability.

TORO SUPER ISOTRONIC design is the result of the collaboration between MASCHIO GASPARDO Research and Development department and Italian School of Design (SID), as design has an increasingly important effect also in the world of agriculture.

TORO SUPER ISOTRONIC is unique and innovative also from this point of view: its captivating lines and refined design recall dynamism-oriented systems that distinguish it from other MASCHIO GASPARDO power harrows.

In the tillage segment, MASCHIO GASPARDO offers several solutions resulting from its long experience in the field, with a range of equipment characterised by great strength, high versatility and ease of use. The attention to details and the continuous innovations confirm the technical competence of MASCHIO GASPARDO Group and the desire to improve its models continuously.
